ELMECO FC1 User Manual

- 21 -
Millennium
Electric
System






1: Main switch
Pr: Pressure switch
LPr: Pressure switch light
C: Compressor
FM: Fan motor
TR: Transformer
7: Fuse 5x20 (2A-20VA/5A-60VA)
9: Fuse 5x20 mm F315mA
EV1-2-3: Solenoid valve
M1-2-3: Gear motor
EB1-2-3: Electronic board
EM: Machine module
H1-2-3: Magnetic or Optical reader
L1-2-3: Top light
P1-2-3: Level probe
R1-2-3: Heating element 100Kohm-
0.25W
A: Suppressor filter (230V/50HZ)
q1-2-3: Thermostat
B: Phase advancing condenser
(FC3 120V/60HZ)
1: 
Pr: 














7:  x 20 (2 
 )
9:  x 20  mA
 Solenoid











 Kohm-0
25 






 )
q 1-2-3: 





)
Colors
BRN Brown 
BLU Blue 
GRN Yellow-Green 
RED Red 
BLK Black 
WHI White 
GRY Grey 
VIO Purple 
ORA Orange 
