ELNA 444 - Threading the Needles

20
w
(A)
(B)
q
z
x
1
2
3
4
5
6
7
8
9
10
Threading the needles
Thread each needle in the following steps:
z Draw the thread through the left side thread guide bar
from back to front as shown (A).
NOTE:
If the thread is coming out from the thread guide notch,
pass the thread through the thread guide hole again as
shown (B)
q Thread guide bar
x Pass the thread through the holes on the left side of
the thread guide plate as illustrated.
w Thread guide plate
