CARE OF YOUR MACHINE
Cleaning the Feed Dogs and Looper Area
WARNING:
Turn the power switch off and unplug the machine
before cleaning.
NOTE:
Do not dismantle the machine in any way other than
what is explained in this section.
z Remove the presser foot and needles.
x Remove the setscrew and needle plate.
c Clean the feed dogs with a lint brush.
q Setscrew
w Needle plate
e Lint brush
v Open the looper cover and clean the looper and
surrounding area with the lint brush.
b Replace the needle plate, needles and presser foot.
Close the looper cover.
r Looper cover
Replacing the Light Bulb
WARNING:
Turn the power off before replacing the light bulb.
The bulb could be HOT, wait until it has cooled down
before touching it.
z Remove the setscrew and face plate.
x Push up and twist the bulb counterclockwise (in the
direction “A”) to remove it.
Push up and twist the bulb clockwise (in the
direction “B”) to replace it.
c Attach the face plate with the setscrew.
q Setscrew
w Face plate
e Light bulb
