ELNA eXperience 620 - Additional Spool Pin

18
t Push bobbin winder spindle to the right. The
computer display screen will show a bobbin winding
“] [“.
y Holding the free end of the thread, press the foot
control. Stop machine after the bobbin has made a
few turns. Cut the thread tail close to the hole in the
bobbin. Start machine again to continue winding
bobbin. When the bobbin is fully wound, stop the
machine.
u Move the spindle to the left to return the bobbin
winder to its original position. Cut the thread as
shown.
Additional Spool Pin
The additional spool pin can be used to wind an extra
bobbin without unthreading the machine.
PROCEDURE: Insert the spool stand w and the
additional spool pin e in the hole q (located to the right
of the built-in spool pin). Place the felt r and spool t on
the pin with the thread coming off the spool as shown.
t
y
u
t
r
e
w
q
