Manuale istruzioni LAVASCIUGA MOD. ZLA40 – ZLA40C – ZLA40CB
8.2.2. key 2: Brush button.
Switches the brush motor on /off.
8.2.3. key 3: Suction button.
Switches the suction on. Switch off has a 5 second delay..
8.2.4. key 5: Led shows waste water level.
On the key there is an led which signals the waste water level is full. This signals the micro
float to open for over 5 seconds.
The micro float is normally a closed contact which opens when the waste tank is full.
When the led is switched OFF the waste tank needs emptying (LED OFF = INDICATES
TANK FULL)
8.2.5. KEY 1:. Start button.
To start the machine press the button.
To stop the machine press the button again.
8.3. Adjusting operations
The adjustments that you can do on the machine to keep it in the best possible working
condition could be:
8.3.1. Adjustment of the lower brush holder
Use the cams that are situated on the extreme part of the lever that raises the brush holder.
This adjustment regulates how much of the brush plate touches the floor, and also the
direction of the machine, in the case of the machine not going perfectly sraight, you need to
adjust the cams, varying the tilt of the brush holder to restore perfect straightness.
The following photos show how to adjust the cams.
05/07/11 Rev .0.0 Lavasciuga Mod.ZLA40 – ZLA40C – ZLA40CB
