Manuale istruzioni LAVASCIUGA MOD. ZLA40 – ZLA40C – ZLA40CB
Fig 22
Fig 23
05/07/11 Rev .0.0 Lavasciuga Mod.ZLA40 – ZLA40C – ZLA40CB
SX cam for side adjustment (
side tilting of the plate
Mode of adjustment: loosen the
small bolt, make the adjustment
on the main nut ( large
hexagonal), tighten the small
bolt.
Position of the cams on the
brush plate
