ESR series service routers.ESR-Series. User manual
284
•
•
•
•
Step Description Command Keys
11 Set the minimum interval after which
the neighbor should generate BFD
message. On the interface (optional).
esr(config-if-gi)# ip bfd min-rx-
interval <TIMEOUT>
<TIMEOUT> – interval after
which the BFD message should
be sent by the neighbor, takes
values in milliseconds in the
range of [200..65535] for
ESR-1000/1200/1500/1511/17
00/3100/3200 and
[300..65535] for
ESR-10/12V(F)/14V(F)/
15/20/21/30/100/200.
By default:
300 ms on
ESR-10/12V(F)/14VF/
15/20/21/30/100/200;
200 ms on
ESR-1000/1200/1500/1
511/1700/3100/3200.
12 Set the minimum interval after which
the BFD message is sent to the
neighbor. On the interface (optional).
esr(config-if-gi)# ip bfd min-tx-
interval <TIMEOUT>
<TIMEOUT> – interval after
which the BFD message should
be sent by the neighbor, takes
values in milliseconds in the
range of [200..65535]
forESR-1000/1200/1500/1511
/1700/3100/3200 and
[300..65535] for
ESR-10/12V(F)/14V(F)/
15/20/21/30/100/200.
By default:
300 ms on
ESR-10/12V(F)/14VF/
15/20/21/30/100/200;
200 ms on
ESR-1000/1200/1500/1
511/1700/3100/3200.
13 Set the amount of dropped packets, at
which the BFD neighbor is considered
to be unavailable. On the interface
(optional).
esr(config-if-gi)# ip bfd multiplier
<COUNT>
<COUNT> – amount of dropped
packets, at which the neighbor
is considered to be unavailable,
takes values in the range of
[1..100].
Defaultvalue: 5.
14 Switch BFD session to the passive
mode, so that BFD messages will not
be sent until the messages from BFD
neighbor are received. On the interface
(optional).
esr(config-if-gi)# ip bfd passive
