ESR series service routers.ESR-Series. User manual
Create a pw-class on the basis of which the virtual channel (pw) will be created later. Since, in this example,
the default parameters will be applied to pw, it will be sufficient to specify the class name:
PE1(config-mpls)# l2vpn
PE1(config-l2vpn)# pw-class for_p2p_VLAN100
PE1(config-l2vpn-pw-class)# exit
Create a new l2vpn of type p2p and add pw to router PE3, take the pw identifier as VID for convenience (in this
case equal to 100):
PE1(config-l2vpn)# p2p to_PE2_VLAN100
PE1(config-l2vpn-p2p)# interface gigabitethernet 1/0/4.100
PE1(config-l2vpn-p2p)# pw 100 3.3.3.3
PE1(config-l2vpn-pw)# pw-class for_p2p_VLAN100
PE1(config-l2vpn-pw)# enable
PE1(config-l2vpn-pw)# exit
PE1(config-l2vpn-p2p)# enable
PE1(config-l2vpn-p2p)# end
Apply the configuration:
