12 BA-en-1022-0802_PGT120
3.4 Outputs
Additional potential-free contacts allow the documentation of tests and the
control of door openers.
Connect via the 6-pin modular socket (Western RJ12) at the rear of the
unit.
The contact is activated via DIP switch 8.
Fig. 4:
Door opener
6 pin socket
Z00583y
165432
5
Door Opener
N/C pin 2 and 3,
N/O pin 3 and 4
Switches as soon as the test object (or both
test objects) are within the limit values.
