4. Operation
4.1 Start-up
The unit can be operated by the external power supply or by a 9 V battery
(see chap. 3.2 Power supply).
The PGT120 has no "ON-OFF" switch. The unit is switched on, when a
measuring plate is pressed or the footwear in series is activated.
The default settings of the unit are set on delivery. With the DIP switches 1
to 8 at the rear of the unit the following options can be programmed:
Default settings (marked bold) and options:
Switch 1
Switch 2 Function
OFF
OFF "OR" (wrist strap or footwear test)
ON
OFF Only shoes
OFF
ON Only wrist strap
ON
ON "AND" (wrist strap and shoe test)
Switch 3
Upper limit for single shoe test
OFF
35 MOhm
ON
70 MOhm
Switch 4
Switch 5 Test voltage
OFF
OFF 30 V
OFF
ON 50 V
ON
ON 100V
Switch 6
Footwear test mode
OFF
Test according to switch 1 and 2
ON
Footwear in series enabled
Switch 7
lower limit
OFF
lower limit disabled
ON
lower limit enabled
Switch 8
Door opener relay
OFF
inacitve
ON
active
