BA-en-1022-0802_PGT120 15
electrostatic
innovations
4.4 Testing footwear separately
Connect the foot electrode to the sockets with the shoe symbol (4, fig. 1)
at the rear of the unit.
DIP switch 3 at the rear of the unit is preset to the upper limit of 70 MOhm
(can be adjusted to 35 MOhm).
DIP switch 1 + 2 at the rear of the unit are set to the "OR" function (default
setting) or to the function "only shoes".
Stand with both shoes on the footwear electrode while pressing the right
measuring plate and keep it pressed. An audible signal indicates that the
tester is switched on. After a short measuring time the test result will be
indicated by a LED:
The tester will be switched off when the measuring plate is released.
Green LED "OK" flashes: The resistance of both shoes is in the range of
100 kOhm to 70 MOhm (35 MOhm) or 0 to 35
MOhm with the lower limit switched off.
Red LED "Hi-Fail right" flashes:
audible signal
The resistance of the right shoe exceeds the
upper limit of 70 MOhm (35 MOhm).
Red LED "Hi-Fail left" flashes:
audible signal
The resistance of the left shoe exceeds the
upper limit of 70 MOhm (35 MOhm).
Red LED "Lo-Fail" right flashes:
audible signal
The resistance of the right shoe is below the
lower limit of 100 kOhm
(
not applicable if the lower limit is switched off).
Red LED "Lo-Fail" left flashes:
audible signal
The resistance of the left shoe is below the
lower limit of 100 kOhm
(
not applicable if the lower limit is switched off).
