16 BA-en-1022-0802_PGT120
4.5 Testing wrist straps and footwear at the same time
DIP switch 1 + 2 at the rear of the unit is set to the AND function.
Put on the wrist strap and connect it via the coil cord to the snap or the
plug (5d, fig. 2) on the left hand side of the unit.
Connect the footwear electrode to the sockets with the shoe symbol
(4, fig. 1) at the rear of the unit.
DIP switch 3 at the rear of the unit is preset to the upper limit of 70 MOhm
(can be adjusted to 35 MOhm).
Stand with both shoes on the footwear electrode while pressing one
measuring plate and keep it pressed. An audible signal indicates that the
tester is switched on. After a short measuring time the test result will be
indicated by a LED:
Warning!
The green LED only flases when the resistance footwear and the
resistance wrist strap are between the limits.
If the wrist strap or the footwear are out of range, the fault will be indicated
by audible and visual (red LED) signals.
Evaluation of the signal identical to the separate tests.
The tester will be switched off when the measuring plate is released.
Green LED "OK" blinking: The resistance of both shoes is in the range of
100 kOhm to 70 MOhm (35 MOhm) and the
resistance wrist strap is in the range of
750 kOhm to 35 MOhm. If the lower limit is
switched off, the lower limit starts at 0 Ohm.
