Key
1 Socket for external power supply
2 Socket for door opener
3 DIP-switches 1 - 8
4 Sockets for footwear electrode
5 Wrist strap test
5a LED Hi-Fail: upper limit exceeded
5b LED Lo-Fail: below low limit
5c Male snap 3 mm
5d Connections for wrist strap test
Male snap 4 mm
Male snap 10 mm
socket 4 mm
6 Footwear test
6a LED Hi-Fail: upper limit exceeded
6b LED Lo-Fail: below low limit
7 LED OK: measured value in the limit
8 Measuring plate for wrist strap test
9 Measuring plate for footwear test
