Eltron LAB+ Series - Command Storage; Image Buffer

Program Sample D5
R0,8
Q256,24
B24,0,0,2,2,5,72,N,"12345-6789"
A24,88,0,4,1,1,N,"Name"
P2
P
X8,2,5,200,30
LO220,2,200,5
P
Command Storage During power-up the:
• Print (image)buffer is cleared
• Form length is set 592 dots with no (0) gap.
• Margins zero offset (0,0)
• Print density is set to level 3.
A P (Print) command clears the print (image)
buffer after each print command is executed.
The form length and gap, margins and print
density setting are not affected by the P com-
mand.
Image Buffer The printer converts all text and graphics into
a image buffer as dots. Each image of text or
graphics is them placed into the image buffer
matrix.
The default image buffer is 432 by 592 dots.
The image buffer absolute size is 255,744 dots.
Changing the width to 256 dots will result in an
image length of 999 dots (4.92inches).
22
980090-001 Rev.B
