A Command - Text
Description This command is used to set the size, type style,
and position of an ASCII text string. 95 ASCII
characters are supported, represented as deci-
mal 32 through 127, excluding character 32
the quote(“).
Syntax Ap
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
,"DATA"
Parameters p
1
= Horizontal start position (X) in dots.
p
2
= Vertical start position (Y) in dots.
p
3
= Rotation
Value Description
0 No rotation
1 90 degrees
p
4
= Font selection
Value Description
1
22.6 cpi, 4.3 points,
(7 x 12 dots)
2
16.9 cpi, 6.4 points,
(10 x 18 dots)
4
12.7 cpi, 7.8 points,
(14 x 22 dots)
Fonts 1, 2 and 4 are fixed pitch. For
character availability maps, see Ap-
pendix B.
980090-001 Rev. B 27
A Command - Text
Description This command is used to set the size, type style,
and position of an ASCII text string. 95 ASCII
characters are supported, represented as deci-
mal 32 through 127, excluding character 32
the quote(“).
Syntax Ap
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
,"DATA"
Parameters p
1
= Horizontal start position (X) in dots.
p
2
= Vertical start position (Y) in dots.
p
3
= Rotation
Value Description
0 No rotation
1 90 degrees
p
4
= Font selection
Value Description
1
22.6 cpi, 4.3 points,
(7 x 12 dots)
2
16.9 cpi, 6.4 points,
(10 x 18 dots)
4
12.7 cpi, 7.8 points,
(14 x 22 dots)
Fonts 1, 2 and 4 are fixed pitch. For
character availability maps, see Ap-
pendix B.
980090-001 Rev. B 27
