Eltron LAB+ Series - Page 35

B Command - Bar Code
Description This command is used to set the barcode type,
size and position of a bar code.
Syntax Bp
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
,p
8
“DATA”
Parameters p
1
= Horizontal start position (X) in dots.
p
2
= Vertical start position (Y) in dots.
p
3
= Rotation
Value Description
0 No rotation
1 90 degrees
p
4
= Bar Code selection
Value Description
1
Code 128
(autoselect A,B or C)
2 Interleaved 2 of 5 (I2/5)
3
Code 3 of 9 (UPS Code 39)
Extended or Not Extended
automatic
P Postnet
p
5
= Narrow bar width*. Acceptable values
are: 2 - 4.
p
6
= Wide bar width*. Acceptable values are:
4 - 12.
p
7
= Bar height*. Acceptable values are:
1- 216.
980090-001 Rev. B 29
B Command - Bar Code
Description This command is used to set the barcode type,
size and position of a bar code.
Syntax Bp
1
,p
2
,p
3
,p
4
,p
5
,p
6
,p
7
,p
8
“DATA”
Parameters p
1
= Horizontal start position (X) in dots.
p
2
= Vertical start position (Y) in dots.
p
3
= Rotation
Value Description
0 No rotation
1 90 degrees
p
4
= Bar Code selection
Value Description
1
Code 128
(autoselect A,B or C)
2 Interleaved 2 of 5 (I2/5)
3
Code 3 of 9 (UPS Code 39)
Extended or Not Extended
automatic
P Postnet
p
5
= Narrow bar width*. Acceptable values
are: 2 - 4.
p
6
= Wide bar width*. Acceptable values are:
4 - 12.
p
7
= Bar height*. Acceptable values are:
1- 216.
980090-001 Rev. B 29
