Installation
Page 10
3 Installation
3.1 Preparing for installation
Figure 4 shows a typical installation configuration for the AIS transceiver. Please take the time to
familiarise yourself with the system elements and their connections prior to attempting
installation.
Figure 4 Typical installation configuration
GPS Antenna
VHF Antenna
Chartplotter
NMEA0183 device
SwitchPower in
NMEA 2000
Optional PC
Class B AIS
transceiver
