Specifications
Page 33
7 Specifications
Parameter Value
Dimensions 116 x 115 x 37 mm (L x W x H)
Weight 150g (AIS transceiver unit only)
Power DC (9.6V - 31.2V)
Average power consumption 170mA at 12VDC
Peak current rating 2A
GPS Receiver (AIS Internal) 50 channel IEC 61108-1 compliant
Electrical Interfaces USB
NMEA0183 38.4kBaud bi-directional
NMEA0183 4.8kBaud bi-directional
NMEA2000 LEN=1
External switch
Connectors VHF antenna connector (SO-239)
GPS antenna connector (TNC)
USB mini-B
NMEA2000 standard connector
12 way power input / NMEA0183 / external switch
VHF Transceiver Transmitter x 1
Receiver x 2 (One receiver time shared between AIS and
DSC)
Frequency: 156.025 to 162.025 MHz in 25 kHz steps
