Specifications
Page 47
9 Specifications
Parameter Value
Dimensions 149 x 118 x 47 mm (L x W x H)
Weight Transceiver only variants 380g
Transceiver with splitter variants 345g
Power DC (9.6V - 31.2V)
Average power consumption
Transceiver only variants 170mA at 12VDC
Transceiver with splitter variants 220mA at 12VDC
Peak current rating
Transceiver only variants 2A
Transceiver with splitter variants 2.5A
GNSS Receiver
(AIS Internal)
50 channel IEC 61108-1 compliant
Electrical
Interfaces
NMEA0183 38,400kBaud
NMEA2000 LEN=1
WiFi 2.4GHz IEEE 802.11 a/b/g/n
Output power +18dBm
Bluetooth V4.0 / Output power +11dBm
Connectors VHF antenna connector (SO-239)
VHF radio connector (SO-239) - applies to transceivers
with splitter variants only
External GNSS antenna connector (TNC)
NMEA2000 connector
12 way power input / NMEA0183/External switch
USB micro-c connector
