Tinyhawk III Plus
steps: Install the provided antennas onto the SMA connectors. When wearing
the goggles, make sure to separate the antennas from the USB power cable
used for charging.
3.2 Transporter II Specifications
Maximum Dimension (excluding antennas, folded state): LxWxH =
155x100x90mm
Weight (excluding battery): Approximately 398g (including head strap
and antennas)
Screen Resolution: 480x800
Display Screen Size: 4.3 inches
Battery: Built-in 1300mAh lithium-ion battery
Operating Voltage: 4.2V-3.7V
Operating Frequency: 5.8GHz frequency band (5658MHz-5945MHz)
Charging System: Built-in USB 1A linear lithium-ion battery charging
system
DVR: Supports up to 32GB TF card, compression format MJPEG, file
format AV
Recording Size: VGA/D1/HD (Three modes available)
Record Time: Off/3 minutes/5 minutes/10 minutes (Selectable)
3.3 Transporter II Operation 3.3.1 Video Channel
Selection
The Transporter II features the Frequency Band Select Button (Button B) and
Channel Select Button (Button C). These buttons allow manual selection of the
correct frequency band and channel. During cycling through bands/channels,
the channel number and frequency will be displayed on the top left corner of
the screen.
Frequency Band Select Button (B): Short press to cycle through
frequency bands in the sequence A-B-E-F-R. For example, if the current
band is E, the first press of Button B will switch to E, the second press will
switch to F, the third press will switch to R, and so on in a continuous
loop.
Channel Select Button (C): Short press to cycle through the eight
available channels in a continuous loop.
Note: Ensure that the Tinyhawk III Plus is powered on and in the correct channel
when cycling through frequencies to select the appropriate frequency band and
channel.
