2
EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide
Device placement requirements
Figure 1 Typical cabinet front and rear views
Before attaching the mounting rails or trays in any cabinet, you must
decide where to put them. Where you install the devices depends on
the kinds of devices you will install and the height of each device.
Position in the cabinet
Devices with internal cooling fans or blowers that move air from
front to back (or vice versa) and not from beneath or above have no
special cooling requirements that direct placement in the cabinet. All
of the storage systems and enclosures mentioned in this document
have fans or blowers that move air from front to back.
EMC220
