EMC Rails and Enclosures (CX3-10 Class and CX3-20 Class Storage Systems) Field Installation Guide
Installing a 3U disk enclosure (DAE3P) in a cabinet
Installing a 3U disk enclosure (DAE3P) in a cabinet
Follow the steps below to install a 3U DAE3P disk enclosure in a
standard 19" NEMA cabinet.
Enclosure mounting kit
Before you start, be sure you have all the materials listed in Table 5.
Tools are not part of your purchased enclosure assembly.
Table 5 Enclosure mounting kit materials
Component Use
2 adjustable rails (20.5-34 inches) Attach front to back on either side
between NEMA channels in a standard
19" cabinet
12 Phillips M5 12.7 mm screws Attach the rail mounting hardware in a
40U cabinet
3U bezel (front rack panel) with keys EMI shielding
(L)
(R)
EMC3248
