DIGITAL CONDUCTIVITY METER
The information contained in the accompanying document is proprietary and confidential, and
may not be copied in any manner whatsoever without prior written consent of Emcee
Electronics, Inc. The document and the material therein may not be used for any purpose other
than that intended by Emcee Electronics, Inc.
COPYRIGHT 2005 EMCEE ELECTRONICS, INC.
REVISION DATE: October 23, 2014
Page 5 of 11
5. APPARATUS
5.1 The Emcee Model 1153 Conductivity Meter complete with probe is shown in Fig.
1.
5.2 The Meter is operated by a single pressure sensitive switch that is covered by and
is directly beneath the Emcee green/white logo as shown in Fig.1. The Switch is used
to retrieve the stored data and to initiate a test.
5.3 The Meter is a portable, hand held device that is battery powered. As shown in
Fig. 2 the batteries can be accessed by removing the top (cap) on the Meter Fig. 1.
5.4 The TOOL shown in Fig. 2 is used as an Allen wrench to remove the 2-screws
that secure the cap to the Meter and to extract the batteries.
Figure 1 – Model 1153 Meter Figure 2 – Batteries, Cap, and Tool
Red LED
MC Logo
Pressure
Sensitive
Switch
LCD
CAP
CAP
Batteries
Allen Head
Screw
Batter
Removal Tool
To Next Page
