Chapter 3 Operation 11
LCU+ Series Controller User Manual
3.1.2 Functions Of Indicators
Table 3-1 Functions of Indicators
Indicator
Normal State
Fault State
Fault Cause
Status (green)
On
Off
If this LED is on, this means the system is operating normally
Observation Alarm
(yellow)
Off
On
The power system has one or more active observation alarms.
Alarm conditions are programmable. Refer to Table 3-3 for defaults
Major Alarm (red)*
Off
On
The power system has one or more active major alarms (Major and
Critical Alarms). Alarm conditions are programmable. Refer to
Table 3-3 for defaults
Note: A Major Alarm initiates an alarm report if alarm report is enabled
3.1.3 Functions Of Controls
Table 3-2 Function of Keys on the Panel
Key Symbol
Key Name
Function
ENT
Enter
Confirm or Execute
▲
Up
Move Up Cursor or Select the Previous Screen
▼
Down
Move Down Cursor or Select the Next Screen
ESC
Escape
Escape or Cancel
3.2 LCD Menu Tree
The overall menu structure is shown in Figure 3-5.
09:20:20
Float
53.4V 404A
Manual Normal
08 -11 -03
Float
53.4V 404A
Manual Normal
ENT
MAIN MENU
Status
Settings
ECO
Manual
Quick Settings
ENT
STATUS
Active Alarm
Rectifiers
History Alarm
SETTINGS
Alarm
Rectifier
Battery
AC
DC
Controller
Communication
Disable
CycPeriod: 168h
Rect
Work: 80%
MANUAL
Sys Mode: Auto
In Manual▼
System Type:
48V / set
Capacity: 300Ah
ECO
▼
Rect Limit: 1
LCD Rotation: On
Figure 3-5 Main menu screen
