Chapter 3 Operation 13
LCU+ Series Controller User Manual
SETTINGS
Alarm
Rectifier
Battery
AC
DC
Controller
Communication
ALARM
Alarm Level
Alarm Control
DI Setting
COMMUNICATION
Address: 1
CommMode: RS232
Protocol: YDN23
BaudRate: 9600
IP/Subnet/Gate:
10.163.210.91
255.255.255.0
10.163.210.1
CallbackTime: 3
PhoneNumber
:
86010677
86010808
RECTIFIER
Position: Disabl
R -Posi: 1-1
HVSD: 59.0V
Default V: 53.5V
Walk-in On: N
Walk-in T: 8s
Interval T: 0s
AC OverV On: N
ACCurrLim : 30A
BATTERY
Basic
Charge
Test
Temp Comp
AC
Over Volt: 280V
Under Volt: 180V
PH Fail: 80V
AC Input: N
AC PH: 3-PH
DC
Over Volt2: 58.2V
Over Volt1: 58.5V
Under V1: 45.0V
Under V2: 45.0V
Amb High: 40C
Amb Low: -5C
CONTROLLER
Lang: English
Tzone: GMT + 08:00
Date: 2009-03-23
Time: 22:17:18
System Type:
48V/1000A
DownloadMode:N
Reset PWD: N
Reset Para: N
Oper1PWD: ******
Oper2PWD: ******
AdminPWD: ******
LVD
Figure 3-7 Settings screen
In the Setting menu, there are 7 items that are ‘Alarm’, ‘Rectifier’, ‘LVD’, ‘AC’, ‘DC’, ‘Controller’ and ‘Communication’
respectively.
Move the cursor to ‘Rectifier’ and press ENT, you can configure the following rectifier parameters:
Position: Enable or disable the shelf setting.
R-Posi: rectifier position in shelf.
HVSD: high voltage shut down, rectifier will shut down when its output voltage exceeds this HVSD point.
Default V: rectifier default output voltage.
Walk-in ON: rectifier walk-in function (soft start) is enabled.
Walk-in T: rectifier walk-in time (soft start time).
Interval T: rectifier sequential startup interval.
AC OverV on: rectifier will shutdown when AC input exceeds AC over voltage point.
ACCurrLim: rectifier current limiting value during startup process.
Move the cursor to ‘AC’ and press ENT, you can configure the following AC parameters:
Over Volt: set the over voltage protection point.
Under Volt: set the under voltage protection point.
PH Fail: set the phase failure voltage point.
