Emerson 8800A - Page 33

2-23
Installation
Table 2-14. Vortex Dual-Sensor Style Flowmeter (4- through 12-in./100 through 300 mm Line Sizes)
Nominal Size
Inch (mm)
Flange
Rating
Face-to-face A
Inch (mm)
(1)
A ANSI RTJ
Inch (mm)
Diameter B
Inch (mm)
(2)
C
Inch (mm)
(3)
Weight
lb (kg)
(4)
4 (100) Class 150
Class 300
Class 600
Class 900
15.2 (386)
16.0 (406)
17.7 (450)
18.7 (475)
15.7 (399)
16.6 (422)
17.7 (450)
18.9 (480)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
68.1 (30,9)
88.2 (40,0)
113.9 (51,7)
137.1 (62,2)
PN 16
PN 40
PN 64
PN 100
PN 160
13.3 (338)
14.4 (366)
15.4 (391)
16.3 (414)
17.1 (434)
–
–
–
–
–
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
9.6 (244)
57.6 (26,1)
66.6 (30,2)
79.6 (36,1)
95.9 (43,5)
103.2 (46,8)
JIS 10K
JIS 20K
JIS 40K
13.6 (345)
13.6 (345)
16.8 (427)
–
–
–
3.79 (96,3)
3.79 (96,3)
3.79 (96,3)
9.6 (244)
9.6 (244)
9.6 (244)
55.4 (25,1)
63.2 (28,7)
93.7 (42,5)
6 (150) Class 150
Class 300
Class 600
19.4 (493)
20.2 (513)
22.2 (564)
19.9 (505)
20.8 (528)
22.3 (566)
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
126.4 (57,3)
165.9 (75,3)
231.9 (105,2)
PN 16
PN 40
PN 64
PN 100
16.8 (427)
18.3 (465)
19.9 (505)
21.5 (546)
–
–
–
–
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
10.8 (274)
112.0 (50,8)
131.7 (59,7)
175.2 (79,5)
204.8 (92,9)
JIS 10K
JIS 20K
JIS 40K
18.5 (470)
18.5 (470)
22.0 (559)
–
–
–
5.7 (144,8)
5.7 (144,8)
5.7 (144,8)
10.8 (274)
10.8 (274)
10.8 (274)
124.0 (56,2)
141.9 (64,4)
220.1 (99,8)
8 (200) Class 150
Class 300
Class 600
24.0 (610)
24.8 (630)
27.0 (686)
24.5 (622)
25.4 (645)
27.1 (688)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
190.1 (86,2)
246.7 (111,9)
345.5 (156,7)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
20.9 (531)
20.9 (531)
22.3 (566)
22.9 (582)
24.7 (627)
26.3 (668)
–
–
–
–
–
–
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
11.7 (297)
160.2 (72,7)
159.0 (72,1)
186.9 (83,4)
205.4 (93,2)
265.1 (120,2)
330.4 (149,9)
JIS 10K
JIS 20K
JIS 40K
22.6 (574)
22.6 (574)
27.0 (686)
–
–
–
7.55 (191,8)
7.55 (191,8)
7.55 (191,8)
11.7 (297)
11.7 (297)
11.7 (297)
178.2 (80,8)
202.6 (91,9)
324.0 (147,0)
10 (250) Class 150
Class 300
Class 600
14.6 (371)
15.8 (401)
19.1 (485)
15.1 (384)
16.4 (417)
19.2 (488)
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
201.5 (91)
289.5 (131)
479.6 (218)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
11.9 (302)
12.1 (307)
13.5 (343)
14.8 (376)
16.4 (417)
18.9 (480)
–
–
–
–
–
–
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
12.8 (325)
160.6 (73)
165.4 (75)
210.7 (96)
249.6 (113)
310.6 (141)
447.3 (203)
JIS 10K
JIS 20K
JIS 40K
14.6 (371)
14.6 (371)
18.1 (460)
–
–
–
9.56 (243)
9.56 (243)
9.56 (243)
12.8 (325)
12.8 (325)
12.8 (325)
177.6 (81)
224.8 (102)
381.6 (173)
12 (300) Class 150
Class 300
Class 600
16.8 (427)
18.0 (457)
20.5 (521)
17.3 (439)
18.7 (475)
20.7 (526)
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
300.3 (136)
417.5 (189)
596.5 (271)
PN 10
PN 16
PN 25
PN 40
PN 64
PN 100
13.2 (335)
13.9 (353)
15.0 (381)
16.9 (429)
18.8 (478)
21.2 (538)
–
–
–
–
–
–
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
13.7 (348)
207.4 (94)
227.7 (103)
272.1 (123)
350.0 (159)
432.8 (196)
645.1 (293)
JIS 10K
JIS 20K
JIS 40K
15.7 (399)
15.7 (399)
19.7 (500)
–
–
–
11.38 (289)
11.38 (289)
11.38 (289)
13.7 (348)
13.7 (348)
13.7 (348)
228.8 (104)
291.4 (132)
508.9 (231)
(1) ±0.14 inch (3.6 mm)
(2) ±0.03 inch (0.8 mm)
(3) ±0.20 inch (5.1 mm)
(4) Add 0.4 Lb (0,2 kg) for display option.
