Rosemount Model 8800C Vortex Flowmeter
2-24
Figure 2-16. Dimensional Drawings for Remote Mount Transmitters
3.20
(81)
2.56
(65)
1.10
(28)
2.85
(72)
1.00
(25)
2.65
(68)
4.50
(114)
2.81
(71)
4.50
(114)
3.06
(78)
2.81
(71)
Display
Option
Terminal Cover
NOTE
Dimensions are in inches (millimeters)
2.00
(51)
2.00
(51)
1.80
(46)
4.90
(124)
5.50
(140)
1
/2-14 NPT
(For Remote
Cable
Conduit)
Electrical Connection ASME B16.5
(ANSI)
1
/2-14 NPT (2 places)
8800-0002A04B, 0002B04B
