iTrust Adapt UPS 20kVA User Manual
Chapter 3 Operation And Display Panel
YYYY MM DD, DD MM YYYY and MM DD YYYY formats can be
selected.
Set the communication baud rate of the USB port
For internal communication only, can not be set
Set the communication baud rate of the SNMP card port
This setting is suitable for RS485 communication
Set the communication mode
If the communication mode of the SNMP card port is Modem, you can
set alarm callback times here
If the communication mode of the SNMP card port is Modem, you can
set phone No.1 here
If the communication mode of the SNMP card port is Modem, you can
set phone No.2 here
If the communication mode of the SNMP card port is Modem, you can
set phone No.3 here
You can change the command password. Default: ā123456ā
Set the battery cell. The setting options include: 30-cell, 32-cell,
34-cell, 36-cell, 38-cell, 40-cell
Set the position of the temperature sensor. āRemoteā only
Set each single in parallel system to share the battery group or not
Set the output voltage system
Set the output system: 3-in 3-out/3-in 3-out
This setting can only be carried out after the EPO operation. After the
setting, you must power off the system, and confirm that the system
actual connection mode complies with the setting. Power on again,
and the setting can come into force
Command (start, stop
battery, system test or
frocing boost charge)
The battery maintenance test will lead to the battery being partly
discharged, for rough assessment of the battery capacity. The load
must range from 20% ~ 100%
The battery capacity test will lead to the battery being completely
discharged, for accurate assessment of the battery capacity. The load
must range from 20% ~ 100%
For UPS self-test. The user actives this function, 5 seconds later, a
pop window will appear to show the result of this test
Manually stop the test, including maintenance test, capacity test and
system test
Manually conduct the forcing charge for battery
Manually stop the forcing boost charge for battery
Provide the monitor software version
Provide the rectifier software version
Provide the inverter software version
Keypad
w
i
ndow
The function of menu buttons (F1 ~ F4 and HELP) is shown in icon mode for the current display screen.
