8. Reverse Switch Operation (Continued)
8.3
Replace the Shade into the opening in the Lower
Housing, aligning the Three Flat Areas on the top edge
of the Shade with the Lower Housing Three Raised
Dimples and turn the Shade Clockwise until it stops
(Figure 41).
NOTE: Periodically check that the Shade is seated
fully clockwise in the Lower Housing.
CLOCKWISE
LOWER HOUSING
RAISED DIMPLES (3)
FLAT AREAS (3)
SHADE
Figure 41
25
emersonfans.com
Please contact 1-800-654-3545 for further assistance
ETL Model No.: CF235
LED LIGHT FIXTURE
ASSEMBLY
REVERSE SWITCH
Figure 40
8.2
Slide the Reverse Switch (located on the side of the
LED Light Fixture Assembly) to the opposite position,
and turn the Ceiling Fan ON again (Figure 40).
The Fan Blades will turn in the opposite direction and
reverse the airflow.
During Summer Months, run the Fan Counter-
Clockwise, as you look up at it, to direct airflow
downward.
During the Winter Months, run the Fan Clockwise, as
you look up at it, to direct airflow upward.
If airflow is desired in the opposite direction, turn the
Ceiling Fan OFF and wait for the Blades to stop turning.
Reverse Switch Information
Season Blade Rotation Direction
Summer Counter-Clockwise
Winter Clockwise
