60
AXI M A 2000/4000 In s ta ll at i on M anua l
U s e t h e t a b le b el o w t o d e t e r m i n e t h e p i n a ss i g n m e n t s o f t h e S T I - 50
i n p u t s a n d o u t p u t s .
I nput s Pi n A ssi gn me nt s O utput s Pi n A ssi gn me nt s
In p u t N u m b e r P i n N u m b e r In p u t N u m b e r P i n N u m b e r
0 37 0 37
1 39 1 39
2 38 2 38
3 40 3 40
4 35 4 35
5 42 5 42
6 36 6 36
7 41 7 41
8 47 8 47
9 50 9 50
10 44 10 44
11 48 11 48
12 49 12 49
13 43 13 43
14 46 14 46
15 45 15 45
16 14 16 14
17 12 17 12
18 13 18 13
19 11 19 11
20 16 20 16
21 9 21 9
22 15 22 15
23 10 23 10
24 4 24 4
25 1 25 1
26 7 26 7
27 3 27 3
28 2 28 2
29 8 29 8
30 5 30 5
31 6 31 6
