Step 2 — Copeland EVM Drive Installation
Dimensions and Weights
Approximate mounting dimensions in inches (mm)
Approximate dimensions in inches (mm)
Frame
size
D H1 H2 W1 W2 W3 Ø
Weight
lb (kg)
FR1
7.09
5.98
5.51
2.83
2.26
2.26
0.20
2.6
(180
(152)
(140) (72) (57.5) (57.5) (5.2)
(1.2)
FR2
7.09
8.66
8.15
4.29
3.56
3.56
0.22
5.7
(180
(220)
(207) (109) (90.5) (90.5) (5.5)
(2.6)
FR3
7.09
10.24
9.72
5.12
4.57
4.57
0.22
8.2
(180
(260)
(247) (130) (116) (116) (5.5)
(3.7)
FR4
7.68
11.81
11.06
7.24
6.3
6.3
0.24
13.9
(195
(300)
(281) (184) (160) (160) (6)
(6.3)
