15. TTL SERIAL LINE
The TTL connector allows, by means of the external module TTL/RS485, to connect the unit to a network
line ModBUS-RTU compatible as the dIXEL monitoring system.
The same TTL connector is used to upload and download the parameter list of the “HOT KEY”.
16. USE OF THE PROGRAMMING “HOT KEY “
The Wing units can UPLOAD or DOWNLOAD the parameter list from its own E2 internal memory to the
“Hot Key” and vice-versa.
16.1 DOWNLOAD (FROM THE “HOT KEY” TO THE INSTRUMENT)
1. Turn OFF the instrument by means of the ON/OFF key, remove the TTL serial cable if present, insert
the “Hot Key” and then turn the Wing ON.
2. Automatically the parameter list of the “Hot Key” is downloaded into the Wing memory, the “DoL”
message is blinking. After 10 seconds the instrument will restart working with the new parameters.
3. Turn OFF the instrument, remove the “Hot Key”, plug in the TTL serial cable and then turn it ON
again.
At the end of the data transfer phase the instrument displays the following messages:
- End for right programming. The instrument starts regularly with the new programming.
- Err for failed programming. In this case turn the unit off and then on if you want to restart the
download again or remove the “Hot key” to abort the operation.
16.2 UPLOAD (FROM THE INSTRUMENT TO THE “HOT KEY”)
1. Turn OFF the instrument by means of the ON/OFF key and remove the TTL serial cable if present;
then turn it ON again.
2. When the unit is ON, insert the “Hot Key” and push the UP
key; the “UPL” message will appear.
3. Push SET key to start the UPLOAD; the “UPL” message will start blinking.
4. Turn OFF the instrument, remove the “Hot Key”, plug in the TTL serial cable and then turn it ON
again.
At the end of the data transfer phase the instrument displays the following messages:
- End for right programming. The instrument starts regularly with the new programming.
- Err for failed programming. In this case turn the unit off and then on if you want to restart the
download again or remove the “Hot key” to abort the operation.
17. ALARM SIGNALS
Alarm output ON. Other outputs unchanged
Alarm output ON. Compressor output according to parameters Con and CoF
Alarm output ON. Defrost termination is timed. No temperature control on fans.
Insert probe 1, 2, 3, failure
Alarm output ON. Other outputs unchanged. The cycle is made by time
Real Time Clock data lost
Alarm output ON. Other outputs unchanged.
Real Time Clock failure
Alarm output ON. Other outputs unchanged. The date and the duration of the
cycle are not available.
Maximum temperature alarm
Alarm output ON. Other outputs unchanged.
Minimum temperature alarm
Alarm output ON. Other outputs unchanged.
Fast freezing interrupted by
short power failure
Alarm output ON. The freezing cycle restart from the same point at which was
interrupted.
Fast freezing interrupted by long
power failure
Alarm output ON. The freezing cycle restart from the current phase.
Max duration of the cycle is
expired
Alarm output ON. Other outputs unchanged. In any case the cycle ends when the
final temperature is reached
Alarm output ON. Other outputs unchanged.
Alarm output ON. Other outputs OFF.
Alarm output ON. Other outputs unchanged.
