1592006207 XB570L GB r1.1 23.03.2015 XB570L 16/20
18. TECHNICAL DATA
Housing: self extinguishing ABS
Case: frontal 185x38 mm; depth 70mm
Mounting: panel mounting in a 150x31mm panel cut-out
Frontal protection: IP65
Connections: screw terminal block ≤ 2.5mm
2
wiring
Power supply: 230Vac, ±10%
Power absorption: 5VA max
Display: dual display
Inputs: 5 PTC or NTC probes
Relay outputs:
Compressor: relay SPST 20(8)A or 8(3) A, 250Vac
Defrost: relay 8(3)A, 250Vac
Fans: relay SPST 8(3)A, 250Vac
Light: relay SPST 16(6)A, 250Vac
Aux1: relay SPST 8(3)A, 250Vac
Aux2: relay SPST 16(6)A, 250Vac
Serial output: RS232 serial output for XB07PR printer connection
Serial output: TTL serial output for monitoring system (MODBUS-RTU) protocol
Data storing: on the non-volatile memory (EEPROM)
Data storage: non-volatile memory (EEPROM)
Kinf of action: 1B
Pollution degree: normal
Software class: A
Operating temperature: 0 to 60°C (32 to 140°F)
Storage temperature: -30 to 85°C (-22 to 185°F)
Relative humidity: 20 to 85% (no condensing)
Measuring range: -55 to 50°C (-67 to 122°F)
NTC probe: -40 to 110°C (-40 to 230°F)
PTC probe: -50 to 150°C (-55 to 302°F)
Resolution: 0.1°C or 1°F (selectable).
Accuracy of the controller at 25°C: ±0.3°C ±1digit
19. STANDARD VALUE OF THE CYCLES.
Cy1: for fast chilling and conservation of foods at positive
temperature
CyS = tEP
iS2 = 5°C (41°F)
Pd3 = OFF
dbC = no
rS2 =-2°C (28°F)
dbH = yes
iS1 = 20°C (68°F)
Pd2 = 2.0 h
HdS = 3°C (37°F)
rS1= -10°C (14°F)
iS3 = 3°C (37°F)
Pd1 = 2.0 h
rS3=-2°C (28°F)
Cy2: for chilling and fast freezing of foods with holding
CyS = tEP
iS2 = 5°C (41°F)
Pd3 = 2.0 h
dbC = no
rS2= -2°C (28°F)
dbH = YES
iS1 = 10°C (50°F)
Pd2 = 2.0 h
HdS =-18°C (0°F)
rS1 = -10°C (14°F)
iS3=-18°C (0°F)
Pd1 = 2.0 h
rS3=-30°C (-22°F)
Cy3: direct fast freezing with holding
CyS = tEP
iS2=-18°C (0°F)
Pd3 = OFF
dbC = no
rS2=-30°C(-22°F)
dbH = yes
iS1 = -18°C (0°F)
Pd2 =OFF
HdS = -18°C (0°F)
rS1=-30°C (-22°F)
iS3 =-18°C (0°F)
Pd1 = 4.0
rS3=-30°C (-22°F)
