Emerson Dixell XB Series User Manual

1592006207 XB570L GB r1.1 23.03.2015 XB570L 17/20
Cy4: direct fast freezing without holding
CyS = tEP
iS2=-18°C (0°F)
Pd3 = OFF
dbC = no
rS2=-30°C (-22°F)
dbH = no
iS1 =-18°C (0°F)
Pd2 =OFF
HdS = OFF
rS1=-30°C (-22°F)
iS3=-18°C (0°F)
Pd1 = 4.0
rS3=-30°C (-22°F)
20. STANDARD VALUES OF THE PARAMETERS.
Lab
Description
Values
Level
Set
Set point
3.0
- - -
Hy
differential
2.0
Pr1
AC
Anti-short cycle delay
1
Pr2
PAU
Time of stand by
0
Pr2
PFt
Maximum acceptable duration of power failure
15
Pr2
Con
Compressor ON time with faulty probe
15
Pr2
COF
Compressor OFF time with faulty probe
10
Pr2
rPO
Thermostat probe calibration
0.0
Pr2
EPP
Evaporator probe presence
YES
Pr2
EPO
Evaporator probe calibration
0.0
Pr2
i1P
Insert probe 1 presence
YES
Pr2
i1o
Insert probe 1 calibration
0.0
Pr2
i2P
Insert probe 2 presence
n
Pr2
i2o
Insert probe 2 calibration
0
Pr2
i3P
Insert probe 3 presence
n
Pr2
i3o
Insert probe 3 calibration
0
Pr2
rEM
Probe selection to stop chilling cycle
iPt
Pr2
CF
Temperature measurement unit
°C
Pr2
rES
Resolution (for °C):
dE
Pr2
Lod
Local display
rP
Pr2
rEd
Remote display
rP
Pr2
d1P
Door switch polarity
cL
Pr2
Odc
Open door control
F-C
Pr2
dOA
Open door alarm delay
5
Pr2
dLc
Stop count down of running cycle
y
Pr2
rrd
Regulation restart after door open alarm
Y
Pr2
d2F
Second digital input function
EAL
Pr2
d2P
Second digital input polarity
cL
Pr2
did
Time delay for digital input alarm
5
Pr2
oA1
First configurable relay function
tMr
Pr2
oA2
Second configurable relay function
ALL
Pr2
oA3
Third configurable relay function
Lig
Pr2
2CH
Compressor setting during the holding
C1
Pr2
OAt
Second compressor switching on delay
3
Pr2
OAS
Set point for second compressor
0
Pr2
OAH
Differential for second compressor
2,0
Pr2
OAi
Probe selection for second compressor
rP
Pr2
OSt
Auxiliary output timer
0
Pr2
OSS
Set point for auxiliary output
0
Pr2
OSH
Differential for auxiliary output
2.0
Pr2
OSi
Probe selection for auxiliary output
rP
Pr2
tdF
Defrost type
rE
Pr2
idF
Interval between defrost cycles
6.0
Pr2
dtE
Defrost termination temperature
8
Pr2
MdF
Maximum length for defrost
20
Pr2
dFd
Temperature displayed during defrost
rt
Pr2
Fdt
Drip time
0
Pr2
dAd
Defrost display time out
20
Pr2
FnC
Fan operating mode
c_n
Pr2
