1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 23/40
toH
Differential for phase-cut regulator: 0 to 100%
Lto
Lower limit for output oA3: input value (FPb) corresponding to the minimum
output power (Po1)
- NTC10k  -40 to 110°C; -40 to 230°F
- NTC86k  -40 to 180°C; -40 to 356°F
- PT1000  -40 to 180°C; -40 to 356°F
- Ratiometric Pressure probe  0.0 to 51.0 bar; 0 to 750 PSI
Uto
Upper limit for output oA3: input value (FPb) corresponding to the maximum
output power (Po2)
- NTC10k  -40 to 110°C; -40 to 230°F
- NTC86k  -40 to 180°C; -40 to 356°F
- PT1000  -40 to 180°C; -40 to 356°F
- 0-5  0.0 to 51.0 bar; 0 to 750 PSI
Po1
Minimum output power (valid if oA3=PCF): 0 to 100%
Po2
Maximum output power (valid if oA3=PCF): 0 to 100%
15.10 ALARMS
LAL
Lower limit for temperature/pressure alarm on suction line (depending on
probe P1):
- P1=NTC10k  -40.0°C to HAL; -40°F to HAL
- P1=NTC86k  -40.0°C to HAL; -40°F to HAL
- P1=PT1000  -40°C to HAL; -40°F to HAL
- P1=0-5  P1i to HAL [bar, PSI]
HAL
Upper limit for temperature/pressure alarm on suction line (depending on
probe P1):
- P1=NTC10k  LAL to 110.0°C; LAL to 230°F
- P1=NTC86k  LAL to 180°C; LAL to 356°F
- P1=PT1000  LAL to 180°C; LAL to 356°F
- P1=0-5  LAL to P1E [bar, PSI]
AdS
Delay for temperature/pressure alarm activation on suction line: 0 to 255 min
ELP
Electronic pressure control threshold (Low pressure alarm on suction line):
- P1=NTC10k, NTC86k, PT1000  -40.0°C to St1; -40°F to St1
- P1=0-5  P1i to St1 [bar, PSI]
CUP
Compressor up time before maintenance: (10 to 9990 hours, res. 10 hours) after
reaching the preset number of hours, the device will show the maintenance warning.
PEn
Max number of pressure control activations (ELP) before stopping regulation:
(0 to 15) after detecting PEn alarms of the ELP type in an interval of time PEi, the
regulation will be stopped
PEi
Interval of time to count the number of ELP alarm events: 0 to 999 min. With
PEi=0 this function is disabled.
SPr
Number of active compressors when probe is in error: 0 to 2
LAF
Lower limit for temperature/pressure alarm on condenser (depending on
probe FPb):
- NTC10k  -40.0°C to HAF; -40°F to HAF
- NTC86k  -40.0°C to HAF; -40°F to HAF
- PT1000  -40°C to HAF; -40°F to HAF
- 0-5 Pxi to HAF [bar, PSI]
HAF
Upper limit for temperature/pressure alarm on condenser (depending on
probe FPb):
- NTC10k  LAF to 110.0°C; LAF to 230°F
- NTC86k  LAF to 180°C; LAF to 356°F
- PT1000  LAF to 180°C; LAF to 356°F
- 0-5  LAF to PxE [bar, PSI]
