Emerson Dixell XC35CX User Manual

1592001530 XC15-35CX EN r1.2 11.04.2017 XC15-35CX 38/40
19.1 BUZZER MUTING AND RELAY DEACTIVATION
If any alarm condition is active, the buzzer can be muted by pressing any button. Moreover,
keeping any button pressed for more than 3 sec will deactivate also the alarm relay.
19.2 TABLE: ALARM CONDITIONS
CODE
DESCRIPTION
DUE TO
ACTION
RESET
Px
Probe error
(x=1, 2, 3, 4)
Probe damaged or
not configured
Change probe or
modify
configuration
Automatic after error condition
ends
HA
High
pressure/temper
ature warning on
suction line
Pressure/temperat
ure out of range
Check cooling
circuit
Automatic after error condition
ends
LA
Low
pressure/temper
ature warning on
suction line
Pressure/temperat
ure out of range
Check cooling
circuit
Automatic after error condition
ends
H2
High
pressure/temper
ature warning on
condenser
Pressure/temperat
ure out of range
Check cooling
circuit
Automatic after error condition
ends
L2
Low
pressure/temper
ature warning on
condenser
Pressure/temperat
ure out of range
Check cooling
circuit
Automatic after error condition
ends
HLL
Low
pressure/temper
ature lockout on
condenser
Pressure/temperat
ure out of range
Check cooling
circuit
Manual after error condition ends
dLt
Discharge line
temperature
warning
Temperature out
of range
Check cooling
circuit
Automatically after temperature
goes below the differential and at
the end of the cooling time
dLL
Discharge line
temperature
lockout
Temperature out
of range
Check cooling
circuit
Manual after temperature goes
below the differential and at the
end of the cooling time
ELP
Electronic
pressure switch
warning
Pressure out of
range
Check cooling
circuit
Automatic after error condition
ends
ELL
Electronic
pressure switch
lockout
Pressure out of
range
Check cooling
circuit
Manual by powering off and on the
device
HP
External high
pressure switch
warning
Pressure out of
range
Check cooling
circuit
Automatic after error condition
ends
LP
External low
pressure switch
warning
Pressure out of
range
Check cooling
circuit
Automatic after error condition
ends
HPL
External high
pressure switch
lockout
Pressure out of
range
Check cooling
circuit
Manual by powering off and on the
device
LPL
External low
pressure switch
lockout
Pressure out of
range
Check cooling
circuit
Manual by powering off and on the
device
