Emerson Dixell XC645CX User Manual

1592001440 XC645CX GB r3.4 31.10.2017.docx XC645CX 51/54
Label
Value
Menù
Description
Range
iF01
oA1
Pr2
Configurable digital input 1 function
(terminals 10-13)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF02
oA2
Pr2
Configurable digital input 2 function
(terminals 10-14)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF03
oA3
Pr2
Configurable digital input 3 function
(terminals 10-11)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF04
oA4
Pr2
Configurable digital input 4 function
(terminals 10-12)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF05
LP1
Pr2
Configurable digital input 5 function
(terminals 9-10)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF06
HP
Pr2
Configurable digital input 6 function
(terminals 25-26)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iF07
LL
Pr2
Configurable digital input 7 function
(terminals 27-28)
nu - OA1- OA2 - OA3 - OA4 - OA5 - OA6 -
InF - LP1 - LP2 - HP - ES - OFF - LL - SIL –
EAL – Co1 – Co2 – Co3 – Co4 – Co5 – Co6
iP01
cL
Pr2
Digital input 1 polarity
OP - CL
iP02
cL
Pr2
Digital input 2 polarity
OP - CL
iP03
cL
Pr2
Digital input 3 polarity
OP - CL
iP04
cL
Pr2
Digital input 4 polarity
OP - CL
iP05
cL
Pr2
Digital input 5 polarity
OP - CL
iP06
cL
Pr2
Digital input 6 polarity
OP - CL
iP07
cL
Pr2
Digital input 7 polarity
OP - CL
d1d
0
Pr2
Dig. input set as oA1 or Co1 activation delay
0 ÷ 255 (sec)
d2d
0
Pr2
Dig. input set as oA2 or Co2 activation delay
0 ÷ 255 (sec)
d3d
0
Pr2
Dig. input set as oA3 or Co3 activation delay
0 ÷ 255 (sec)
d4d
0
Pr2
Dig. input set as oA4 or Co4 activation delay
0 ÷ 255 (sec)
d5d
0
Pr2
Dig. input set as oA5 or Co5 activation delay
0 ÷ 255 (sec)
did
20
Pr2
Liquid level alarm, signaling delay
0 ÷ 255 (min.)
didA
20
Pr2
External alarm, signaling delay:
0 ÷ 255 (min.)
ALMr
no
Pr2
Manual reset for compressor/fan alarms
no - yES
dEU
tPr
Pr2
Displaying measurement unit: pressure or
temperature
tMP - PrS
CF
°C
Pr2
Measurement unit for temperature
°C - °F
PMU
Bar
Pr2
Measurement unit for pressure
BAr - PSI - PA
rES
dE
Pr2
Resolution for display and parameters
in - dE
dFE
no
Pr2
Pressure filter enabling
no - yES
dEU1
tPr
Pr2
Upper display: pressure or temperature
selection
tMP - PrS
dSP2
P2
Pr2
Lower display default visualization
nu - P1 - P2 - P3 - P4 - StC1 - StC2 - SEtF
dEU2
tPr
Pr2
Lower display: pressure or temperature
selection
tMP - PrS
Pbd
5.0
Pr2
Proportional band for compressors regulation
0.1÷30.0(°C); 1÷50 (°F); 0.1÷10.0(BAR);
1÷150(PSI) 10÷1000(KPA)
rS
0.0
Pr2
Band offset
-12.0÷12.0(°C) -20÷20(°F) -12.0÷12.0(BAR)
-200÷ 200(PSI) -999÷999(KPA)
inC
500
Pr2
Integral time
0 ÷ 999 sec
dGSP
no
Pr2
Digital compressor always activated as first
compressor
no - yES
SUt
2
Pr2
Digital input valve on at start up
0÷3s
