Emerson Dixell XC645CX User Manual

1592001440 XC645CX GB r3.4 31.10.2017.docx XC645CX 52/54
Label
Value
Menù
Description
Range
tdS
15
Pr2
Cycle time for digital compressor
10÷40s
PM
30
Pr2
Minimum capacity for digital compressor
10÷PMA(dGty=ScrL) 0÷PMA(dGty=StrM)
PMA
100
Pr2
Maximum capacity for digital compressor
PM÷100
ton
60
Pr2
Time with digital compr. at PMA value before
starting a load
0÷255s
toF
30
Pr2
Time with digital compr. at PM before turning
off a load
0÷255s
MinP
0
Pr2
Minimum capacity threshold to start the
safety lubrication function
0÷100
tMin
180
Pr2
Max time at MinP to start the safety
lubrication function
1÷255min
tMAS
3
Pr2
Time at PMA for digital compressor to restore
the right lubrication
1÷255min
ESC
0.0
Pr1
Energy saving for compressors regulation
-50.0÷50.0(°C) -90÷90(°F) -20.0÷20.0(BAR)
-300÷300(PSI) -2000÷2000(KPA)
OnOn
5
Pr2
Minimum delay between 2 switching on of the
same compressor
0 ÷ 255 (min.)
OFOn
1
Pr2
Delay between the switching off and on of the
same compressor
0 ÷ 255 (min.)
don
01:00
Pr2
Time delay between the insertion of two
different loads
0 ÷ 99.5 (min.10sec)
doF
00:30
Pr2
Time delay between switching off of two
different compressors
0 ÷ 99.5 (min.10sec)
donF
1:00
Pr2
Minimum time a stage stays ON
0 ÷ 99.5 (min.10sec)
MAon
0
Pr2
Maximum time a stage stays switched ON
0 ÷ 24 (hour)
FdLy
no
Pr2
'don' delay enabled also for the first request
no - yES
FdLF
no
Pr2
'doF' delay enabled also for the first switching
off
no - yES
odo
20
Pr2
Regulation delay at power on
0 ÷ 255 (sec.)
LSE
-40.0
Pr2
Minimum set point (compressors)
-50.0÷HSE(°C) -58.0÷HSE(°F)
PA04÷HSE(BAR,PSI,KPA)
HSE
10.0
Pr2
Maximum set point (compressors)
LSE÷150.0(°C) LSE÷302(°F)
LSE÷PA20(BAR , PSI , KPA)
Lit
90.0
Pr2
Set point for liquid injection
0.0 ÷ 180.0°(°C) 32 ÷ 356(°F)
Lid
10.0
Pr2
Differential for liquid injection
0.1 ÷ 25.5° (°C) 1 ÷ 50° (°F)
LiPr
nP
Pr2
Probe selection for liquid injection
nP - P3 - P4
Pb
5.0
Pr2
Proportional band for fan regulation
0.1÷30.0(°C) 1÷50 (°F) 0.1÷10.0(BAR)
1÷150(PSI) 10÷1000(KPA)
ESF
0.0
Pr2
Energy saving differential for fan regulation
-50.0÷50.0(°C) -90÷90(°F) -20.0÷20.0(BAR)
-300÷300(PSI) -2000÷2000(KPA)
PbES
0.0
Pr2
Band offset for fan regulation in ES
-50.0÷50.0(°C) -90÷90(°F) -20.0÷20.0(BAR)
-300÷300(PSI) -2000÷2000(KPA)
Fon
30
Pr2
Time delay between the insertion of two
different fan
0 ÷ 255 (sec)
FoF
15
Pr2
Time delay between switching off of two
different fan
0 ÷ 255 (sec)
LSF
10.0
Pr2
Minimum set point (fan)
-50.0÷HSF(°C) -58.0÷HSF(°F)
FA04(FPb)÷HSF(BAR , PSI , KPA)
HSF
50.0
Pr2
Maximum set point (fan)
LSF÷150.0(°C) LSF÷302(°F) LSF÷FA20
(BAR , PSI , KPA)
PAO
30
Pr2
Alarm probe delay at power on
0 ÷ 255 (min.)
LAL
-40.0
Pr1
Pressure alarm set low limit (compressors)
-50.0÷HAL(°C); -58÷HAL(°F);
PA04÷HAL(BAR , PSI , KPA)
HAL
10.0
Pr1
Pressure alarm set high limit (compressors)
LAL÷150.0(°C); LAL÷302(°F);
LAL÷PA20(BAR , PSI , KPA)
