15
Value of reference in
rpm
RO Shows reference in rpm.
1.069
Info
16
Hz sent from
controller
RW
Can see speed sent from controller
here
1.021
Info
20
Preset Speed 2
(Manual) RW Use this to set manual / test speed.
1.022
Manual
21 Preset Selector 0 or 2
Use this to turn on manual / test
speed.
1.015
Manual
30 Current Trip (Trip 0) RO Gives code for current trip. (Trip 0) 10.020 Trip
31 Trip 1 RO Previous trip - before Trip 0 10.021 Trip
32 Trip 2 RO Previous trip - before Trip1 10.022 Trip
33 Trip 3 RO Previous trip - before Trip 2 10.023 Trip
34 Trip 4 RO Previous trip - before Trip 3 10.024 Trip
35 Trip 5 RO Previous trip - before Trip 4 10.025 Trip
36 Trip 6 RO Previous trip - before Trip 5 10.026 Trip
37 Trip 7 RO Previous trip - before Trip 6 10.027 Trip
38 Trip 8 RO Previous trip - before Trip 7 10.028 Trip
39 Trip 9 RO Previous trip - before Trip 8 10.029 Trip
Table 1 - Menu 0 Guide
