Emerson EWD2004OM Supplement Service Manual

20040227 1-18-5 H9600EL
CHIP CERAMIC CAP.(1608) CH J 47pF/50V
or
CHD1JJ3CH470
CHIP CERAMIC CAP. CG J 47pF/50V CHD1JJ3CG470
C1221 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1222 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMASSL100
C1223 CHIP CERAMIC CAP. B K 1000pF/50V or CHD1JKB0B102
CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C1224 CHIP CERAMIC CAP. B K 1000pF/50V or CHD1JKB0B102
CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C1245 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1246 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1247 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1249 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
C1351 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EKB0B104
CHIP CERAMIC CAP. B K 0.1µF/16V or CHD1CKB0B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/25V
or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C1352 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C1354 CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJBCH101
CHIP CERAMIC CAP.(1608) CH J 100pF/
50V or
CHD1JJ3CH101
CHIP CERAMIC CAP. CG J 100pF/50V CHD1JJ3CG101
C1355 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C1394 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMASSL470
C1395 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1421 CHIP CERAMIC CAP. B K 0.01µF/50V or CHD1JKB0B103
CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1422 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EKB0B104
CHIP CERAMIC CAP. B K 0.1µF/16V or CHD1CKB0B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/25V
or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C1441 CHIP CERAMIC CAP. B K 0.33µF/10V or CHD1AKB0B334
CHIP CERAMIC CAP.(1608) B K 0.33µF/
10V
CHD1AK30B334
C1442 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1461 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C1462 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1481 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C1482 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C1522 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C1523 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
Ref. No. Mark Description Part No.
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C1524 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C1531 CHIP CERAMIC CAP. B K 0.01µF/50V or CHD1JKB0B103
CHIP CERAMIC CAP.(1608) B K 0.01µF/
50V
CHD1JK30B103
C1532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C2002 CHIP CERAMIC CAP. B K 1000pF/50V or CHD1JKB0B102
CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V H7 CE0KMAVSL101
C2012 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
DIODES
D013 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 or NDWZ000BA158
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D015 SCHOTTKY BARRIER DIODE SB370 NDQZ000SB370
D016 SCHOTTKY BARRIER DIODE SB340 or NDQZ000SB340
SCHOTTKY BARRIER DIODE SB340 NDWZ000SB340
D019 PCB JUMPER D0.6-P10.0 JW10.0T
D030 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 or NDWZ000BA158
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D031 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D040 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D052 ZENER DIODE DZ-10BSBT265 or NDTB00DZ10BS
ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D080 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D081 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D082 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D100 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D101 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D501 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D502 A SWITCHING DIODE 1N4148M or NDTZ01N4148M
A SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D504 ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D510 A SWITCHING DIODE 1N4148M or NDTZ01N4148M
A SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D555 LED MIE-534A2 or NPZZM1E534A2
LED SIR-563ST3F P or QPQPS1R563ST
LED SIR-563ST3F Q QPQQS1R563ST
D564 B,C,D LED(RED) 204HD/E NPQZ00204HDE
D565 B,C,D LED(RED) 204HD/E NPQZ00204HDE
D566 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D567 LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D571 LED(RED) 204HD/E NPQZ00204HDE
D701 ZENER DIODE DZ-33BSDT265 or NDTD00DZ33BS
Ref. No. Mark Description Part No.
