Emerson EWD2004OM Supplement Service Manual

20040227 1-18-6 H9600EL
ZENER DIODE MTZJT-7733D QDTD00MTZJ33
D1001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1003 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1004 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1007 CARBON RES. 1/4W J 68k Ω RCX4JATZ0683
D1008 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1010 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 or NDWZ000BA158
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D1011 RECTIFIER DIODE BA158 or NDQZ000BA158
RECTIFIER DIODE BA158 or NDWZ000BA158
RECTIFIER DIODE ERA22-10 QDPZ0ERA2210
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1016 A RECTIFIER DIODE FR101 NDWZ000FR101
D1017 A ZENER DIODE DZ-18BSBT265 or NDTB00DZ18BS
A ZENER DIODE MTZJT-7718B QDTB00MTZJ18
D1020 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE SB140 NDWZ000SB140
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1031 PCB JUMPER D0.6-P5.0 JW5.0T
D1036 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1037 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1038 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1058 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 NDWZ001N4005
D1301 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS
ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D2001 B,C,D LED(GREEN) 204-10GD/S957 NPQZ10GDS957
D2002 B,C,D LED(GREEN) 204-10GD/S957 NPQZ10GDS957
ICS
IC301 IC:Y/C/A LA71205M-MPB-E QSZBA0RSY037
IC451 A IC:HIFI LA72670BM-MPB-E QSZBA0RSY039
IC501 MICROCONTROLLER 8BIT
MN101D08DFT
QSZAA0RMS017
IC571 A FL DRIVER IC PT6313-S-TP NSZBA0TG2006
IC751 IC:SWITCH TC4053BF(N) or QSMBA0STS002
IC:SWITCH BU4053BCF or QSMDA0SRM010
IC:ANALOG MULTIPLEXERS
CD4053BCSJX
NSZBA0TF3071
IC1001
#
PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
# PHOTOCOUPLER EL817A or NPEA000EL817
# PHOTOCOUPLER EL817B or NPEB000EL817
# PHOTOCOUPLER EL817C or NPEC000EL817
# PHOTOCOUPLER PS2561A-1(Q) or QPEQPS2561A1
Ref. No. Mark Description Part No.
# PHOTOCOUPLER PS2561A-1(W) or QPEWPS2561A1
# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC1002 VOLTAGE REGULATOR PQ070XZ5MZP QSZBA0TSH034
IC1004 VOLTAGE REGULATOR BA3948FP-E2 QSZBA0TRM073
IC1201 IC:OP AMP KIA4558P or NSZBA0SJY004
IC:OP AMP NJM4558D QSZBA0SJR006
IC1402 DRIVER FOR DVD MM1637XVBE QSZBA0TMM102
COILS
L009 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K LLBD00PKT001
L251 PCB JUMPER D0.6-P5.0 JW5.0T
L303 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L304 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K LLBD00PKT001
L421 INDUCTOR 47µH-K-5FT LLARKBSTU470
L422 PCB JUMPER D0.6-P5.0 JW5.0T
L451 A PCB JUMPER D0.6-P5.0 JW5.0T
L501 PCB JUMPER D0.6-P5.0 JW5.0T
L502 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K LLBD00PKT001
L503 INDUCTOR 12µH-K-26T LLAXKATTU120
L504 PCB JUMPER D0.6-P5.0 JW5.0T
L701 INDUCTOR 4.7µH-K-26T LLAXKATTU4R7
L771 PCB JUMPER D0.6-P5.0 JW5.0T
L1001# LINE FILTER 27MH TLF14CB2730R4 or LLBG00ZTU034
# LINE FILTER 27MH CSA-LF199A LLBG00ZSA008
L1004 BEAD CORE B16 RH 3.5X10X1.3 XL03010XM001
L1007 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K LLBD00PKT001
L1020 CHOKE COIL 47µH-K or LLBD00PKV007
CHOKE COIL 47µH-K or LLBD00PKV005
CHOKE COIL 47µH-K LLBD00PKT001
L1350 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
L1351 INDUCTOR(0.47µH K) LAP02TAR47K LLAXKATTUR47
L1401 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L1441 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L1442 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L1461 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L1481 CHIP RES.(1608) 1/10W 0 Ω or RRXAZB5Z0000
CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
L1522 INDUCTOR 47µH-K-5FT LLARKBSTU470
L2001 INDUCTOR(100µH K) LAP02TA101K LLAXKATTU101
TRANSISTORS
Q031 TRANSISTOR KTA1267(Y) or NQSY0KTA1267
TRANSISTOR KTA1267(GR) or NQS10KTA1267
TRANSISTOR 2SA1175(J) or QQSJ02SA1175
TRANSISTOR 2SA1175(H) or QQSH02SA1175
TRANSISTOR 2SA1175(F) QQSF02SA1175
Q052 RES. BUILT-IN TRANSISTOR KRC103M or NQSZ0KRC103M
RES. BUILT-IN TRANSISTOR BA1F4M-T QQSZ00BA1F4M
Q055 TRANSISTOR KTC3198(Y) or NQSY0KTC3198
TRANSISTOR KTC3198(GR) or NQS40KTC3198
Ref. No. Mark Description Part No.
