Emerson FB1200 Field Replacement Guide

FB1100/FB1200 Flow Computer Sensor Assembly Field Replacement Guide
D301842X012
November 2020
iii
Table 1. FB1100 Sensor Assembly Part Numbers (Use Selection Column to Generate UL-listed Kit Number)
Integral Sensor
Selection
Differential Pressure Range & Accuracy
Approvals
25 Inches H2O (62.3 mbar) DP, 0.1% Accuracy
Notes:
 0.1% Accuracy is not available on Traditional Flange.
 25" DP option is available only with static pressure options G4
or A4 and the maximum pressure is limited to 2000 psi.
 Available only with stainless steel sensor & coplanar flange.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
B221
250 Inches H2O (623 mbar) DP, 0.1% Accuracy
Note: 0.1% Accuracy is not available on Traditional Flange.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
B222
250 Inches H2O (623 mbar) DP, 0.075% Accuracy
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
B122
1000 Inches H2O (2.5 bar) DP, 0.1% Accuracy
Notes:
 0.1% Accuracy is not available on Traditional Flange.
 1000" DP range with 0.1% accuracy available only with
Stainless steel sensor and coplanar flange.
 1000" DP range not available with 300 psi static pressure.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
B223
1000 Inches H2O (2.5 bar) DP, 0.075% Accuracy
Note: 1000" DP range not available with 300 psi static pressure.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
B123
Static Pressure Range - for use with Multivariable Sensor (B22* or B12* above)
MV 300 psi gauge (20.7 barg)
Note: 1000" DP range not available with 300 psi static pressure.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
G6
MV 300 psi absolute (20.7 bara)
Note: 1000" DP range not available with 300 psi static pressure.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
A6
MV 1500 psi gauge (103.4 barg)
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
G7
MV 1500 psi absolute (103.4 bara)
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
A7
MV 3600 psi gauge (250 barg)
Note:
When used with 25" DP option, maximum working pressure
is 2000 psi/137.9 Bar.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
G4
MV 3600 psi absolute (250 bara)
Note:
When used with 25" DP option, maximum working pressure
is 2000 psi/137.9 Bar.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
A4
Sensor Material & Flange Type
Stainless Steel Sensor and Coplanar Flange
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
2E12
Hastelloy Diaphragm and Hastelloy Coplanar Flange
Note:
Not available with a 1000" 0.1% accuracy sensor or a 25"
sensor.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
3E13
Stainless Steel Sensor and Traditional Flange
Note:
0.1% Accuracy is not available on Traditional Flange.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
2F12
Sensor Material Certificates
Not Required
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
Q0R
3.1 B Traceability certs to EN 10205
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
Q8R
NACE MRO 175/ISO 15156 requires Hastelloy Diaphragm
Option
Note: Available only with 3E13.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
Q15R
NACE MRO 103 - requires Hastelloy Diaphragm Option
Note:
Available only with 3E13.
Class 1 Div 2 UL, IEC Ex N, ATEX Ex N
Class 1 Div 1 UL, IEC Ex d, ATEX Ex d
Q25R
