Instruction Manual
D103292X012
C1 Controllers and Transmitters
March 2017
2
Contents (Continued)
Parts Kits 41...................................
Parts List 41...................................
Common Parts 41.............................
Mounting Parts for Panel, Wall, Pipestand
or Actuator Mounting 50.....................
Introduction
Scope of Manual
This instruction manual provides installation, operating, maintenance, and parts information for the Fisher C1 pressure
controllers and transmitters shown in figure 1. Refer to separate instruction manuals for information regarding the
control valve, actuator, and accessories.
Do not install, operate, or maintain C1 pressure controllers and transmitters without first being fully trained and
qualified in valve, actuator, and accessory installation, operation, and maintenance. To avoid personal injury and
property damage, it is important to carefully read, understand, and follow all the contents of this manual, including
all safety cautions and warnings. If you have any questions about these instructions, contact your Emerson
Automation Solutions sales office before proceeding.
Description
The C1 pneumatic pressure controllers and transmitters use a bellows or Bourdon tube sensing element to sense the
gauge pressure, vacuum, compound pressure, or differential pressure of a liquid or gas. The controller or transmitter
output is a pneumatic pressure signal that can be used to operate a final control element, indicating device, or
recording device.
Unless otherwise noted, all NACE references are to NACE MR0175 / ISO15156 & NACE MR0103.
Specifications
Specifications for the C1 controllers and transmitters are listed in table 1. Table 2 explains available configurations and
options.
Educational Services
For information on available courses for C1 controllers and transmitters, as well as a variety of other products, contact:
Emerson Automation Solutions
Educational Services - Registration
Phone: +1-641-754-3771 or +1-800-338-8158
e-mail: education@emerson.com
http://www.emersonprocess.com/education
