Instruction Manual
D102748X012
DLC3010 Digital Level Controller
Introduction and Specifications
May 2018
13
Figure 1‐4. Style Number of Equalizing Connections
STYLE 1
TOP AND BOTTOM CONNECTIONS,
SCREWED (S-1) OR FLANGED (F-1)
STYLE 2
TOP AND LOWER SIDE CONNECTIONS,
SCREWED (S-2) OR FLANGED (F-2)
STYLE 3
UPPER AND LOWER SIDE CONNECTIONS,
SCREWED (S-3) OR FLANGED (F-3)
STYLE 4
UPPER SIDE AND BOTTOM CONNECTIONS,
SCREWED (S-4) OR FLANGED (F-4)
