Emerson Fisher Fieldvue DVC6010f User Manual

DVC6000f Series
March 2006
5-172
Table 5-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Custom Points CUSTOM_POINTS Transducer 51 5-47
Cycle Count CYCLE_COUNT Transducer 73 5-34, 5-50, 7-6
Cycle Count Alrt Pt CYCLE_COUNT_ALRT_PT Transducer 77.6 5-34, 5-56
Cycle Count DB CYCLE_COUNT_DB Transducer 77.7 5-34, 5-56
Cycle Selection CYCLE_SEL Resource 20 5-14
Cycle Type CYCLE_TYPE Resource 19 5-14
DD Resource DD_RESOURCE Resource 9 5-12
DD Revision DD_REV Resource 13 5-13, 7-3
Detailed Status DETAILED_STATUS Resource 52 5-18
Deviation High Alarm DV_HI_ALM PID 64 5-92
Deviation High Limit DV_HI_LIM PID 57 5-84, 5-91
Deviation High Priority DV_HI_PRI PID 56 5-84, 5-91
Deviation Low Alarm DV_LO_ALM PID 65 5-92
Deviation Low Limit DV_LO_LIM PID 59 5-84, 5-91
Deviation Low Priority DV_LO_PRI PID 58 5-84, 5-91
Device ID DEVICE ID Resource 54 5-18, 7-2
Device Record DEVICE_RECORD Transducer 86 5-59
Device Revision DEV_REV Resource 12 5-13, 7-3
Device State RS_STATE Resource 7 5-12, 7-4
Device String Array DEV_STRING Resource 43 5-17
Device Type DEV_TYPE Resource 11 5-13, 7-2
Diag Options DIAG_OPTIONS Resource 45 5-17, 7-3
Disable Analog Input 1 DISABLE_1 ISEL 15 5-104, 5-107
Disable Analog Input 2 DISABLE_2 ISEL 16 5-104, 5-107
Disable Analog Input 3 DISABLE_3 ISEL 17 5-104, 5-107
Disable Analog Input 4 DISABLE_4 ISEL 18 5-104, 5-107
Disable Analog Input 5 DISABLE_5 ISEL 29 5-104, 5-108
Disable Analog Input 6 DISABLE_6 ISEL 30 5-104, 5-108
Disable Analog Input 7 DISABLE_7 ISEL 31 5-104, 5-108
Disable Analog Input 8 DISABLE_8 ISEL 32 5-104, 5-109
Discrete Alarm DISC_ALM DI 24 5-165
Discrete Limit DISC_LIM DI 23 5-160, 5-165
Discrete Priority DISC_PRI DI 22 5-165
Drive Current DRIVE_CURRENT Transducer 54 5-31, 5-47
Drive Current Alrt Pt DRIVE_CURRENT_ALRT_PT Transducer 76.4 5-31, 5-55
Drive Current Alrt Time DRIVE_CURRENT_TIME Transducer 76.5 5-31, 5-55
Drive Signal DRIVE_SIGNAL Transducer 53 5-31, 5-47, 7-5
Effective Area EFFECTIVE AREA Transducer 85.2 5-38, 5-59
Elect Active ELECT_ACTIVE Transducer 74.1 5-30 5-51
Elect Enable ELECT_ENABLE Transducer 75.1 5-30, 5-54
Electronics Serial Number ELECTRONICS_SN Resource 49 5-17, 7-2
Enviro Active ENVIRO_ACTIVE Transducer 74.3 5-32, 5-51
Enviro Enable ENVIRO_ENABLE Transducer 75.3 5-32, 5-54
Error ERROR PID 67 5-92
Factory Serial Number FACTORY_SN Resource 50 5-18, 7-2
Failed Active FAILED_ACTIVE Transducer 59 5-39, 5-48
Failed Alarm FAILED_ALM Transducer 56 5-47
Failed Enable FAILED_ENABLE Transducer 62 5-30, 5-49
Failed Pri FAILED_PRI Transducer 68 9-3, 5-50
Failed Suppress FAILED_MASK Transducer 65 9-3, 5-30, 5-49
−Continued−
