Emerson Fisher Fieldvue DVC6010f User Manual

All Blocks
March 2006
5-173
Table 5-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
Fault State FAULT_STATE Resource 28 5-15, 7-4
Fault State Time FSTATE_TIME
AO 23 5-70, 5-74
DO 19 5-149, 5-152
Fault State Value FSTATE_VAL AO 24 5-70, 5-74
Fault State Value Discrete FSTATE_VAL_D DO 20 5-149, 5-152
Features FEATURES Resource 17 5-13, 7-3
Feature Selection FEATURE_SEL Resource 18 5-5, 5-14, 5-149, 7-3
Feedback Conn FEEDBACK_CONN Transducer 42.4 5-24, 5-37, 5-44
Feed Forward Gain FF_GAIN PID 42 5-83, 5-89
Feed Forward Scale FF_SCALE PID 41 5-83, 5-89
Feed Forward Value FF_VAL PID 40 5-83, 5-89
Field Serial Number FIELD_SN Resource 51 5-6, 5-18, 7-2
Field Value FIELD_VAL AI 19 5-126, 5-127, 5-132
Field Value Discrete FIELD_VAL_D DI 17 5-160, 5-161, 5-164
Flow Direction FLOW_DIRECTION Transducer 84.5 5-37, 5-58
Flow Tends To FLOW_TENDS_TO Transducer 84.7 5-37, 5-58
Free Space FREE_SPACE Resource 24 5-14
Free Time FREE_TIME Resource 25 5-14
Function Block Options FB_OPTIONS Resource 44 5-17, 7-3
Gain GAIN PID 23 5-80, 5-88
Grant Deny GRANT_DENY
AI 12 5-132
AO 13 5-73
DI 12 5-164
DO 13 5-152
ISEL 9 5-106
OS 12 5-121
PID 12 5-87
Resource 14 5-13
Transducer 40 5-43
Hard Types HARD_TYPES Resource 15 5-13
Hardware Revision HARDWARE_REV Resource 48 5-17
Health Index HEALTH_INDEX Transducer 79 5-57
High Alarm HI_ALM
AI 34 5-133
ISEL 46 5-110
PID 61 5-91
High High Alarm HI_HI_ALM
AI 33 5-133
ISEL 45 5-109
PID 60 5-91
High High Limit HI_HI_LIM
AI 26 5-126, 5-133
ISEL 38 5-105, 5-109
PID 49 5-84, 5-90
High High Priority HI_HI_PRI
AI 25 5-126, 5-133
ISEL 37 5-105, 5-109
PID 48 5-84, 5-90
High Limit HI_LIM
AI 28 5-126, 5-133
ISEL 40 5-105, 5-109
PID 51 5-84, 5-90
High Priority HI_PRI
AI 27 5-126, 5-133
ISEL 39 5-105, 5-109
PID 50 5-84, 5-90
Hystval HYSTVAL OS 22 5-121
−Continued−
