Table 5-85. Block Parameter Index (Continued)
Label Page Numbers
Index
Number
BlockParameter Name
IDeadBand IDEADBAND PID 74 5-93
Inlet Pressure INLET_PRESSURE Transducer 83.7 5-37, 5-58
Input IN PID 15 5-87
Input 1 IN_1 ISEL 11 5-104, 5-106
Input 2 IN_2 ISEL 12 5-104, 5-107
Input 3 IN_3 ISEL 13 5-104, 5-107
Input 4 IN_4 ISEL 14 5-104, 5-107
Input 5 IN_5 ISEL 25 5-104, 5-108
Input 6 IN_6 ISEL 26 5-104, 5-108
Input 7 IN_7 ISEL 27 5-104, 5-108
Input 8 IN_8 ISEL 28 5-104, 5-108
Input Array IN_ARRAY OS 16 5-121
Input Char INPUT_CHAR Transducer 50 5-29, 5-46, 7-6
I/O Options IO_OPTS
AI 13 5-132
AO 14 5-70, 5-71, 5-73
DI 13 5-160, 5-164
DO 14 5-149, 5-152
ITK Version ITK_VER Resource 41 5-17, 7-3
Leak Class LEAK_CLASS Transducer 84.2 5-37, 5-58
Length Units LENGTH_UNITS Transducer 92 5-35, 5-60
Lever Style LEVER_STYLE Transducer 85.10 5-38, 5-59
Linearization Type L_TYPE AI 16 5-127, 5-132
Lockval LOCKVAL OS 18 5-121
Low Alarm LO_ALM
AI 35 5-134
ISEL 47 5-110
PID 62 5-91
Low Cutoff LOW_CUT AI 17 5-128, 5-132
Lower Bench Set LOWER_BENCH_SET Transducer 85.4 5-38, 5-59
Low Limit LO_LIM
AI 30 5-126, 5-133
ISEL 42 5-105, 5-109
PID 53 5-84, 5-90
Low Low Alarm LO_LO_ALM
AI 36 5-134
ISEL 48 5-110
PID 63 5-91
Low Low Limit LO_LO_LIM
AI 32 5-126, 5-133
ISEL 44 5-105, 5-109
PID 55 5-84, 5-90
Low Low Priority LO_LO_PRI
AI 31 5-126, 5-133
ISEL 43 5-105, 5-109
PID 54 5-84, 5-90
Low Priority LO_PRI
AI 29 5-126, 5-133
ISEL 41 5-105, 5-109
PID 52 5-84, 5-90
MAI Channel 1 MAI_CHANNEL_1 Transducer 95.1 5-60
MAI Channel 2 MAI_CHANNEL_2 Transducer 95.2 5-60
MAI Channel 3 MAI_CHANNEL_3 Transducer 95.3 5-60
MAI Channel 4 MAI_CHANNEL_4 Transducer 95.4 5-60
MAI Channel 5 MAI_CHANNEL_5 Transducer 95.5 5-60
MAI Channel 6 MAI_CHANNEL_6 Transducer 95.6 5-60
MAI Channel 7 MAI_CHANNEL_7 Transducer 95.7 5-60
MAI Channel 8 MAI_CHANNEL_8 Transducer 95.8 5-60
−Continued−
