Emerson Fisher FIELDVUE DVC6200 Series User Manual

Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
July 2017
39
2. If the DVC6200 SIS and solenoid valve are powered together:
D Install an LC340 line conditioner to allow HART communication over the segment. Refer to the
D LC340 instruction manual (D102797X012
) for more information.
D Connect the logic solver output card +/ terminals to the corresponding LC340 SYS +/ terminals.
D Connect the digital valve controller LOOP +/ terminals to the corresponding LC340 FLD +/ terminals.
Note
For the digital valve controller to operate with a 024 VDC voltage control signal the DIP switches must be in the “Multi” position
and the “Hardware Shutdown Disabled” position, as shown in figure 28 and table 2. The control mode must also be set to digital
with a user interface tool. These are set at the factory when ordered properly.
3. Proceed to Step 4—Configure the Digital Valve Controller on page 33.

Emerson Fisher FIELDVUE DVC6200 Series Specifications

General

Manufacturer	Emerson
Series	FIELDVUE DVC6200
Type	Digital Valve Controller
Communication Protocol	HART
Operating Temperature Range	-40 to 85 °C (-40 to 185 °F)
Enclosure Rating	NEMA 4X, IP66
Material	Aluminum, Stainless Steel
Hazardous Area Certifications	ATEX, IECEx, FM, CSA
Input Signal	4-20 mA, HART
Power Supply	Loop-powered
Supply Pressure	1.4 to 6.0 bar
Certifications	SIL3 capable
Diagnostics	Advanced Valve Diagnostics
