Safe Use Instructions - FloBoss 103 Page 2
Form A6150
SPECIFICATIONS
POWER
External Power Charging Input: 8-28 V dc,
reverse polarity protection.
Input Current: 5 mA nominal. 9.5 mA at 100% duty
cycle.
ENCLOSURE
Housing and Cap: Die-cast aluminum alloy with
iridite plating and paint. Investment cast stainless
steel (CF8M) version available.
ENVIRONMENTAL
Operating Ambient Temperature: -40 to 75°C.
LCD Display: -20 to 75°C.
Storage Temperature: -50 to 85°C.
Operating Humidity: 5 to 95%, non-condensing.
WEIGHT
6.58 kg (aluminum); 12.1 kg (SST).
DVS SENSOR (OPTIONAL)
DIFFERENTIAL PRESSURE INPUT
Range: 0 - 62.2 kPa.
Reference Accuracy: ±0.075% or ±0.10% of URL
(includes linearity, hysteresis, and repeatability
effects).
STATIC PRESSURE INPUT
Range: Either Absolute or Gauge:
0 – 5516 kPa.
0 – 25,000 kPa.
Reference Accuracy: ±0.075% or ±0.10% of URL
(includes linearity, hysteresis, and repeatability
effects).
Stability: ±0.1% of upper range limit for 12 months.
APPROVALS:
ATEX Version
Evaluated per the following standards:
EN 60079-0 (2004)
EN 60079-1 (2004)
IEC 60529 (2001)
Certified by LCIE as Model W40116.
ATEX Cert LCIE 03ATEX6221 X
Product Markings for Hazardous Locations:
Ex d IIB T5 (T
ambient
=75°C), IP66.
II 2 G. 0081.
IECEx Version (Flameproof and Type N)
Evaluated per the following standards:
IEC 60079-0 (2000) Edition 3.1
IEC 60079-1 (2003), 5
th
Edition
IEC 60079-15 (1987)
IEC 60079-15 (2001), 2
nd
Edition
IEC 60529 (2001)
Certified by CSA as Model W40149.
IEC Cert IECEx LCI 08.0015 (Type N)
IEC Cert IECEx LCI 08.0039 (Flameproof)
Product Markings for Hazardous Locations:
Ex d IIB T5 (T
ambient
=75°C)
Ex nAL IIC T3 (T
ambient
=75°C), IP66.
IECEx Version (Type N Only)
Evaluated per the following standards:
IEC 60079-15 (1987)
IEC 60079-15 (2001), 2
nd
Edition
IEC 60529 (2001)
Certified by CSA as Model W40150.
IEC Cert IECEx LCI 08.0015 (Type N)
Product Markings for Hazardous Locations:
Ex nAL IIC T3 (T
ambient
=75°C), IP66.
The following tools are required for installation,
maintenance, and troubleshooting:
IBM-compatible personal computer.
ROCLINK 800 Configuration software.
Phillips-head screwdriver.
Flat-head screwdriver.
Hex socket wrench (M4).
1. You receive the FloBoss 103 in a box. Remove it
from the box.
2. Find a suitable location for the FloBoss 103.
When choosing an installation site, be sure to check
all clearances. Provide adequate clearance for
wiring and service. The optional LCD should be
visible and accessible for the on-site operator. See
Figure 8.
3. Mounting of the FloBoss 103 can be
accomplished using one of the following methods:
Pipestand mounted to a 2-inch pipestand. Use
the standard Rosemount 2" (50mm NB) pipe
mounting kit (with impulse tubing connecting the
FloBoss 103 to the meter run). Ensure that the
pipestand meets all weight requirements and
installation conforms to local building codes. See
Figure 9.
Note: The Rosemount pipe mounting kit is not
suitable for the stainless steel housing.
Customers must provide an appropriate
mounting.
