24 FXMP25 User Guide
www.controltechniques.com Issue Number: 3
4 Not used
5 (+10V) 10V user output
Function Supply for Analog input terminal
Voltage tolerance 2 %
Rated output current 5 mA
Protection
Over 5 mA, the current is limited, but
there is no trip (Voltage is less than 10 V
if the current is higher than 5 mA)
6 (If) Field current output signal
7 (Va) Armature voltage output signal
Type Single-ended voltage
Voltage range 0 to 10 V
Maximum output current 5 mA
Load resistance 2 kΩ min
Protection 5 mA short circuit protection
Resolution 10 bits
Update period 4 ms
8 Fail relay common
9 Fail relay normally open
10 Fail relay normally closed
Function
FXMP25 OK indicator (See Pr 01 and
Pr 27.
Type Form C
Rating
250/125 Vac category 1/2
5 A nominal resistive load
5 A 30 Vdc
Contact condition
Energized when power applied and
FXMP25 OK
Update period 4 ms
Status relay contact is over-voltage category II.
